TURNBUCKLE DIN 1478 24707 24708 24709 Admin Edit

24701 24702 24703 24704 24705 24706 24707 24708 24709


Product Description

Item No

Dimension(mm)

d1

d4

d6

b

l1

l3

l4

l5

adjustable

24701

M 6

6

9

8,5

110

80

80

172 - 262

90

24702

M 8

8

10

11,0

110

84

84

182 - 267

85

24703

M 10

8

14

13,5

125

105

105

213 - 308

95

24704

M 12

10

16

15,5

125

115

115

238 - 328

90

24705

M 16

10

22

19,0

170

165

165

320 - 440

120

24706

M 20

12

24

20,5

200

167

167

367 - 507

140

24707

M 24

12

27

26,0

255

205

205

447 - 627

180

24708

M 30

16

31

33,0

255

255

255

512 - 672

160

24709

M 36

16

37

44,0

295

276

276

568 - 748

180
