Product Description

TWO-MAGNETIC CIRCUIT LIFTER

Construction:Two-magnetic circuit lifters have strong magneitc path by NdFeb magnetic materials.On and off the magnetic path is controlled by turning the manual nozzle.Higher magnetism.less weight and less remaining magnetism when being off,which makes a more reasonable structure.Especially for handle,its new designs enable its damper strength on operating is only 30%-40% compared with the single-magnetic ones.Thin magnetic-inductive material can also be lifted as long as their thickness is more than 5mm.As a result,they are in a more widely use than single-magnetic circuit lifters.
   Safety factor:3:1











Item No.

01865

01866

01867

01868

Rated lifting strengthkgf

300

600

1000

2000

Cylindrical lifting strengthkgf

100

200

300

600

Max pull-off strengthkgf

900

1800

3000

6000

Dimension(mm)B

150

162

189

231

L

162

234

304

304

H

55

78

87

87

R

155

220

265

265

Operation temperature<°C

<80

<80

<80

<80

N.W.kg

10.5

22

38

77
