BEAM CLAMP - X TYPE Admin Edit
| Product Introduction: . Beam clamp is a equipment that can quick form hanger or connecting point in I-beam monorail. . The beam clamp should be formed a complete set with chain hoist or other lifting machines. . The beam clamp was installed on the bottom flange of I-beam. . The beam clamp is adopt left and right screw thread construction for leading screw.clamping is quick in operation. . The scopes of adjustments is wide, adjustment is very convenient. . Main parts of support strength are made by alloy steel. | |||||
| Item No. | 01781 | 01782 | 01783 | 01784 | |
| Capacity | (kg) | 1000 | 2000 | 3000 | 5000 |
| I-beam width range | (mm) | 75-200 | 100-250 | 150-300 | 150-300 |
| Dimensions(mm) | Amax | 240 | 280 | 330 | 330 |
| B | 320 | 360 | 430 | 450 | |
| C | 80 | 90 | 117 | 127 | |
| H | 230 | 300 | 360 | 390 | |
| D | 24 | 31 | 39 | 45 | |
| G | 45 | 63 | 75 | 96 | |
| Фd | 14 | 20 | 24 | 30 | |
| t | 17 | 20 | 25 | 35 | |
| δ | 4.5 | 6 | 10 | 12 | |
