DUAL MAST AERIAL WORK PLATFORM Admin Edit
| Suitable for 1-2 person to work upraised Maximum platform height available: 8m, 10m, and 12m Power supply available: Single phase AC 1. Single phase AC220V 50Hz 2. Working and charging simultaneity. For DC chargeable power adaptor, there are two formats: 1. Working and charging time staggered. 2. Working and charging simultaneity. Emergency switch for up and down without electric power. | ||||||
| Item No | 03371 | 03372 | 03373 | 03374 | ||
| Max.platform height | mm | 6000 | 8000 | 10000 | 12000 | |
| Max.working height | mm | 7700 | 9700 | 11700 | 13700 | |
| Ratedload | kg | 325 | 300 | 300 | 200 | |
| The number of persons allowed on platform | Person(s) | 2 | 2 | 2 | 2 | |
| Platform size | A×B | mm | 1090×600 | 1210×600 | 1450×600 | 1450×600 |
| Outriggerfootprint | C×D | mm | 1690×1650 | 1880×1770 | 2230×1960 | 2550×2570 |
| Power rating | AC | kw | 0.75-1.5 | 0.75-1.5 | 0.75-1.5 | 0.75-1.5 |
| DC | 1.5 | 1.5 | 1.5 | 1.5 | ||
| Storeddimension | L×W×H | mm | 1440×840×1800 | 1560×840×1920 | 1790×840×1920 | 1790×890×2140 |
| Machineweight | kg | 500 | 570 | 728 | 825 | |
