PP ROPE SLINGS (EYE TO EYE) 04627 04628 04629 04630 04631 Admin Edit
According to DIN 1492-4,both ends with spliced eyes, | |||
| Item No | Rope Dia. | Load Capacity? | Splicing Length |
mm | (kg) | mm | |
| 04621 | 6 | 59 | 100 |
| 04622 | 8 | 104 | 100??? |
| 04623 | 10 | 138 | 150??? |
| 04624 | 12 | 195 | 150 |
| 04625 | 14 | 269 | 200 |
| 04626 | 16 | 333 | 200 |
| 04627 | 18 | 425 | 250 |
| 04628 | 20 | 512 | 250 |
| 04629 | 22 | 614 | 300 |
| 04630 | 24 | 717 | 300 |
| 04631 | 30 | 1080 | 350 |
